Calefaciens Equipment
Aqua boiler tubus electrici calefactionis est fabrica ad aquam calefaciendam adhibita, quae intra aquam calefacientis inauguratur et facta est ex ferro immaculato vel aliis materiis corrosioni-resistentibus. Firmitatem et diuturnitatem in usu diuturno conservare potest. Haec fistula electrica calefactionis componitur ex pluribus filis resistentiae spiralibus conformatis, quae in materia velit involuta ne ultrices current. Cum vena per fila resistentia transit, fila resistentia calefacient, aquam circumfusam calefacere. Haec methodus calefactionis efficiens, celeriter, et aqua calida brevi tempore praebet. aqua boiler electrici fistulae calefactionis late adhibitae sunt in officiis, scholis, valetudinariis, hotels et aliis locis, ut aquam calidam hominibus praebeant. Etiam adhiberi possunt in campis industrialibus pro instrumento calefactorio sicut boilers et in commutationibus caloris.
Parameter detail
Product Parameter
Explosio-probatio LABIUM immersionem calefacientis specificationem
| Specifications | Potentia Kw | Flanged immersionem calefacientis Liquid | Flanged calefacientis Air | Temperatus imperium range | Potestas Supple | ||
| magnitudine (mm) | Nobis (pieces of u) | magnitudine (mm) | Nobis (pieces of u) | ||||
| XTFL-5 | 5 | DN80*500 | 3 | DN100*600 | 3 | RT-700 | Unius pascha 220v |
| XTFL-10 | 10 | DN80*700 | 3 | DN100*700 | 6 | Tres phase380V,50HZ | |
| XTFL-15 | 15 | DN125*700 | 6 | DN125*700 | 9 | ||
| XTFL-20 | 20 | DN150*800 | 6 | DN150*900 | 9 | ||
| XTFL-30 | 30 | DN150*800 | 9 | DN150*1000 | 12 | ||
| XTFL-40 | 40 | DN200*1000 | 12 | DN200*1200 | 15 | ||
| XTFL-50 | 50 | DN200*1000 | 12 | DN200*1200 | 15 | ||
| XTFL-60 | 60 | DN200*1200 | 15 | DN250*1300 | 18 | ||
| XTFL-80 | 80 | DN250*1400 | 18 | DN250*150 | 18 | ||
| XTFL-100 | 100 | DN250*1600 | 18 | DN300*1600 | 24 | ||
| XTFL-120 | 120 | DN250*1600 | 18 | DN300*1600 | 27 | ||
| XTFL-150 | 150 | DN300*1600 | 24 | DN350*1600 | 36 | ||
| XTFL-180 | 180 | DN300*1600 | 27 | DN350*1800 | 36 | ||
| XTFL-200 | 200 | DN300*1800 | 27 | DN400*1800 | 45 | ||
| XTFL-240 | 240 | DN350*1800 | 36 | DN400*1800 | 54 | ||
| XTFL-280 | 280 | DN350*1800 | 36 | DN500*160 | 72 | ||
| XTFL-300 | 300 | DN400*1800 | 42 | DN500*160 | 72 | ||
| XTFL-360 | 360 | DN400*1800 | 45 | DN500*1800 | 72 | ||
| XTFL-400 | 400 | DN400*1800 | 54 | DN600*1800 | 84 | ||
| XTFL-450 | 450 | DN450*1800 | 60 | DN600*1800 | 90 | ||
| XTFL-500 | 500 | DN500*1800 | 72 | DN700*1800 | 108 | ||
| XTFL-600 | 600 | DN600*1800 | 84 | DN800*1800 | 120 | ||
| XTFL-700 | 700 | DN600*1800 | 90 | DN900*1800 | 144 | ||
| XTFL-800 | 800 | DN700*1800 | 108 | DN900*1800 | 180 | ||
| XTFL-900 | 900 | DN800*1800 | 120 | DN900*1800 | 180 | ||
| XTFL-1000 | 1000 | DN900*1800 | 144 | DN1000* 1800 | 216 | ||
